Cebek 8-Channel Industrial RF Transmitter



Cebek 8-Channel Industrial RF Transmitter

Specifications:
Reference TL-39
Group 2
Carrier Frequency 433.92 MHz
Maximum Input 12VDC
Number of Channels 8
Range 300m
Consumption 100mA
Power Supply 12VDC
Dimensions 72 x 65 x 30mm
Weight 58g
Technical Information > Download the Handbook for full specifications and applications
The Cebek TL-39 is a eight channel high power industrial transmitter module for Cebek RF remote control receivers. Using the certified radio frequency signal of 433.92 MHz. the transmitter will emit a coded signal to the receivers, allowing it to switch off or on the receivers relay. This module is designed for installation applications and would be operated by external contacts or switches. To personalise remote controls you have more than 13,122 combinations to select from, the required code is easily selected thanks to the PCB mounted DIL switches.
Will Operate with the following Receivers
Four Channel (12Vdc) Momentary Action TL-22
Four Channel (12Vdc) Latching Action TL-23
Single Channel (12Vdc) Latching/Momentary TL-26
Two Channel (12Vdc) Latching/Momentary TL-27
Re-Transmission Booster TL-99

Related Products::
Power Supply FE-103
Antenna C-0509

Order Code   Each
TL-39 Cebek 8-Channel Industrial RF Transmitter 31.28
