Cebek 5V Power Supply 1A



Cebek 5V Power Supply 1A

Specifications:
Reference FE-121

Output 5VDC@1A
Ripple 5mV
Power Supply 230VAC
Dimensions 72 x 99 x 40mm
Weight 448g
Technical Information > Download the Handbook for full specifications and applications
The Cebek FE-121 module is a single rail 5VDC stabilized power supply. It can deliver a maximum of 1A, the output is fully regulated and short circuit protected. A PCB mounted pre-set potentiometer is supplied to adjust the output voltage (3  - 8VDC), to allow for long cable runs and supply voltage variations. The FE-121 module has a small enclosed transformer mounted on the circuit board. and LED to indicate its operating.

Related Products::




Order Code   Each
FE-121 Cebek 5V Power Supply 1A 14.25
