Cebek 24V Power Supply 170mA



Cebek 24V Power Supply 170mA

Specifications:
Reference FE-115

Output 24VDC@170mA
Ripple 5mV
Power Supply 230VAC
Dimensions 75 x 65 x 35mm
Weight 268g
Technical Information > Download the Handbook for full specifications and applications
The Cebek FE-115 module is a single rail 24VDC stabilized power supply. It can deliver a maximum of 170mA, the output is fully regulated and short circuit protected. A PCB mounted pre-set potentiometer is supplied to adjust the output voltage (22 - 27VDC), to allow for long cable runs and supply voltage variations. The FE-115 module has a small enclosed transformer mounted on the circuit board. and LED to indicate its operating.

Related Products::




Order Code   Each
FE-115 Cebek 24V Power Supply 170mA 10.84
