Cebek Group Counter



Cebek Group Counter

Specifications:
Reference CD-46
Range 1 -999
Relay 5A
Consumption 55mA
Power Supply 12VDC
Dimensions 92 x 59 x 30mm
Weight 76g
Technical Information > Download the Handbook for full specifications and applications
The Cebek CD-46 module is a hole number counter. With the use of PCB DIL switches a number between 1 and 999 can be selected then the relay output will energise each time the indicated pulse number will coincide with the pre-selected number. The output will be maintained connected till the next pulse, this process will be automatically renewed, or you do a reset It doesn’t use display, the count up/down is done in internal mode. Received pulses are indicated through a LED.

Related Products::
Power Supply FE-103



Order Code   Each
CD-46 Cebek Group Counter 22.80
